VFP-G SERIES LARGE TORQUE,MULTI STATION PRECISION HEAVY WARM FORGING MACHINE (SECONDARY DRIVE)

The advantage of secondary drive kinetic energy lies in the double flying wheels. After being driven by big and small gears, the action speed is 60%slower than that of primary drive, and the flywheel inertia is large, 50%higher than that of primary drive. In forging al uminum alloy forgings and copper forgings, because of the slow strike speed and good forming effect, it is superior to the primary drive, and is used for die forging and finishing forgings of nonferrous metal s in batches. The forged forgings have the advantages of high precision, high utilization rate of materials, high productivity, easy automation, and low requirements for workers' operation technology.

Contact Now E-Mail Telephone

Product Details

Technical parameter	Unit	VFP-600G	VFP-800G	VFP-1000G
Ability	Tons	600	800	1000
Slider stroke	mm	175	200	250
Slide Adjustment	mm	10	10	10
Number of trips	Spm	65	60	60
Maximum clamping height	mm	555	695	755
Slider bottom panel	mm	755×640	780×700	920×800
Table panel	mm	950×770	1010×900	1120×980
Main motor	Kw×p	45×6	55×6	75×6

VFP-1300G	VFP-1600G	VFP-2000G	VFP-2500G	VFP-3150G	VFP-4000G
1300	1600	2000	2500	3150	4000
250	300	300	350	350	350
15	15	15	15	15	15
60	55	55	55	55	55
845	915	1000	1050	1100	1150
980×860	1100×1000	1250×1100	1350×1100	1350×1200	1500×1390
1190×1050	1340×1100	1440×1200	1540×1200	1600×1500	1600×1600
90×6	132×6	160×6	185×6	200×6	250×6
